· Max 25 fps@5MP (16:9 video output)
· CVI/CVBS/AHD/TVI switchable
· Active deterrence with warm light and siren
· Built-in PIR, 10 m/110°detecting range/angle
· 3.6 mm fixed lens (2.8 mm optional)
· Max. IR length 30 m, Smart IR
· IP67, 12 V DC
Technical Specification
Camera
Image Sensor 5MP
Max. Resolution 1/2.7″CMOS
Pixel 2880 (H) × 1620 (V)
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25 s–1/100,000 s
NTSC: 1/30 s–1/100,000 s
S/N Ratio 0.005 Lux/F1.6, 30 IRE, 0 Lux IR on
Min. Illumination > 65 dB
Illumination Distance 30 m (98.4 ft)
Illuminator On/Off Control Auto
Illuminator Number 1 (IR light)
Pan/Tilt/Rotation Range
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 2.8 mm; 3.6 mm
Max. Aperture F1.6
Field of View 2.8 mm: H: 113°; V: 60°; D: 132°
3.6 mm: H: 90°; V: 48°; D: 104°
Iris Type Fixed iris
Close Focus Distance
2.8 mm: 1.0 m
3.6 mm: 1.5 m
DORI
Distance
Lens Detect Observe Recognize Identify
2.8 mm 61.2 m
(200.8 ft)
24.5 m
(80.4 ft)
12.2 m
(40.0 ft)
6.1 m
(20.0 ft)
3.6 mm 77.8 m
(255.2 ft)
31.1 m
(102.0 ft)
15.6 m
(51.2 ft)
7.8 m
(25.6 ft)
Video
Frame Rate
CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps;
NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps
AHD:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
TVI:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
CVBS:
PAL: 960H;
NTSC: 960H
Resolution
5M (2880 × 1620);
4M (2560 × 1440);
1080p (1920 ×1080);
960 H (960 × 576/960 × 480)
Day/Night Auto switch by ICR
www.dahuasecurity.com
BLC BLC/HLC/DWDR
WDR DWDR
White Balance Auto/Area WB
Gain Control Auto
Noise Reduction 2D NR
Smart IR Yes
Mirror Off/On
Privacy Masking Off/On (8 area, rectangle)
PIR
Detection Mode Pyroelectric infrared sensor
Max. Detection Range 10 m(32.8 ft), 110°
Recommended Installation
Height 2.2 m–3 m (7.2 ft-9.8 ft)
Recommended Working
Temperature –10 °C to 50 °C (14 °F to 122 °F)
Active Deterrence
White Light Warning
lighting/flash;
Alert Duration:5 s–60 s;
flash Freq: low/medium/high
Sound Warning
Audio 1/2/3;
Volume: high/medium/low;
duration: 5 s–60 s; 110 dB
Certifications
Certifications
CE (EN55032:2015, EN61000-3-2:2014, EN61000-
3-3:2013, EN55024:2010+A1:2015, EN55035:2017,
EN50130-4:2011+A1:2014)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
IEC 62368-1:2014 (Second Edition)
Port
Video Output Video output choices of CVI/TVI/AHD/CVBS by one
BNC port
Power
Power Supply DC12 V±30%
Power Consumption Max 4.9 W (12 V DC, IR on)
Environment
Operating Temperature –40 °C to +60 °C (–40 °F to 140 °F); < 95% (non-condensation)
Storage Temperature –40 °C to +60 °C (–40 °F to 140 °F); < 95% (non-condensation)
Protection Grade IP67
Structure
Casing
Cover: Metal
Rear: Plastic
Camera Dimensions 168.8 mm × 79 mm × 79 mm (6.65″ × 3.11″ × 3.11″)
Net Weight 0.32 kg (0.71 lb)
Gross Weight 0.45 Kg (0.99 lb)
