Technical Specification |
||
|
Mode |
ASR1102A(V2) |
ASR1102A-D(V2) |
|
System |
||
|
Main Processor |
8 Bit |
|
|
Read |
||
|
Read Format |
13.56MHz |
125KHz |
|
Read Range |
6-8cm (max.) |
|
|
Reading time |
<0.1s |
|
|
Fingerprint |
||
|
Capacity |
3000 |
|
|
Response Time |
=0.5s |
|
|
Recognition Time |
=1.5s |
|
|
FAR |
=0.00004% |
|
|
FRR |
=0.15% |
|
|
Function |
||
|
Tamper Alarm |
Yes |
|
|
Interface |
||
|
To Controller |
RS485 |
|
|
General |
||
|
LCD Display |
Blue backlight |
|
|
Beep Tone |
Buzzer |
|
|
Power Supply |
9-15VDC/100mA |
|
Working Environment |
-5°C-+55°C |
|
Working Humidity |
5%~95% |
|
Dimension(W×D×H) |
165mm*57mm*29mm |
|
Weight |
0.25kg |
