Más información
|
System |
|
|
Main Processor |
Dual-core embedded processor |
|
Operating System |
Embedded LINUX |
|
Audio and Video |
|
|
IP Camera Input |
16 Channel |
|
Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
|
Display |
|
|
Interface |
1 HDMI, 1 VGA |
|
Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Multi-screen Display |
16CH: 1/4/8/9/16 |
|
OSD |
Camera title, Time, Camera lock, Motion detection, Recording |
|
Recording |
|
|
Compression |
H.264+/H.264 |
|
Resolution |
6Mp/5Mp/4Mp/3Mp/1080P/ 720P/ D1&etc. |
|
Record Rate |
80Mbps |
|
Bit Rate |
16Kbps ~ 20Mbps Per Channel |
|
Record Mode |
Manual, Schedule(Regular(Continuous), MD, Stop |
|
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
|
Video Detection and Alarm |
|
|
Trigger Events |
Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips |
|
Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), and Tampering |
|
Alarm input |
N/A |
|
Relay Output |
N/A |
|
Playback and Backup |
|
|
Sync Playback |
4CH: 1/4 |
|
8CH: 1/4/8 |
|
|
Search Mode |
Time /Date, MD and Exact Search (accurate to second) |
|
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
|
Backup Mode |
USB Device/Network |
