System |
|
Main Processor |
Quad-core embedded processor |
Operating System |
Embedded LINUX |
Display |
|
Interface |
1 HDMI, 1 VGA |
Resolution |
3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768 |
Multi-screen Display |
8CH: 1/4/8/9 |
16/32CH: 1/4/8/9/16 |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Video Detection and Alarm |
|
Trigger Events |
Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Tampering |
Alarm input |
4 Channel, Low Level Effective, Green Terminal Interface |
Relay Output |
2 Channel, NO/NC Programmable, Green Terminal Interface |
Playback and Backup |
|
Playback |
8CH: 1/4/8 |
16/32CH: 1/4/8/16 |
|
Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
Backup Mode |
USB Device/Network |
Storage |
|
Internal HDD |
2 SATA III Port, Up to 6 TB capacity for each HDD |
HDD Mode |
Single |
eSATA |
N/A |
Auxiliary Interface |
|
USB |
2 USB Ports (1 USB2.0, 1 USB3.0) |
RS232 |
N/A |
RS485 |
N/A |
Third-party Support |
|
Third-party Support |
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more |
