Dimensions (W X D X H) | 169 x 116 x 35 mm |
---|---|
External Power Supply | 5VDC/0.6A |
Antenna Type | 3 x 5dBi fixed omni directional antennas |
Signal Rate |
11n: Up to 300Mbps (Dynamic) 11g: Up to 54Mbps (Dynamic) 11b: Up to 11Mbps (Dynamic) |
Button | Reset/WPS button |
Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Frequency | 2.4 – 2.4835GHz |
Reception Sensitivity |
270M: -70dBm@10% PER 130M: -74dBm@10% PER 108M: -74dBm@10% PER 54M: -77dBm@10% PER 11M: -87dBm@8% PER 6M: -90dBm@10% PER 1M: -98dBm@8% PER |
Interfaces |
3 10/100Mbps LAN ports 1 10/100Mbps WAN port |
Certifications | CE, ROHS |
Package Contents |
300Mbps Wireless N Router MW305R Power adapter Quick installation guide |
Environment |
Operating temperature: 0°C ~ 40°C (32°F ~ 104°F) Storage temperature: -40°C ~ 70°C (-40°F ~ 158°F) Operating humidity: 10% ~ 90%, non-condensing Storage humidity: 5% ~ 90%, non-condensing |
Transmission Power | <20dBm |
Wireless Security | 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK |
Wireless Functions | WDS bridge |
WAN Type | Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
Management |
Parental Control Access control Local management Remote management |
DHCP | Server |
Port Forwarding | Virtual server, UPnP, DMZ |
Dynamic DNS | DynDNS?NO-IP |
Firewall Security | IP and MAC address binding |
Protocols | IPv4 |
Guest Network | 2.4GHz guest network |
